TPIU asynchronous clock prescaler register (TPIU_ACPR)
Address offset: 0x010
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
rw
Bits 31:13 Reserved, must be kept at reset value.
Bits 12:0 PRESCALER[12:0]: selects the baud rate for the asynchronous output, TRACESWO
The baud rate is given by the TRACELKIN frequency divided by (PRESCALER +1).
38.11.4
TPIU selected pin protocol register (TPIU_SPPR)
Address offset: 0x0F0
Reset value: 0x0000 0001
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:2 Reserved, must be kept at reset value.
Bits 1:0 TXMODE[1:0]: selects the protocol used for trace output
0x0: reserved (parallel trace port mode not supported in this device)
0x1: Asynchronous SWO using Manchester encoding
0x2: Asynchronous SWO using NRZ encoding
0x3: reserved
