CPU1 breakpoint unit (FPB)

The FPB allows the user to set hardware breakpoints. It contains six comparators that
monitor the instruction fetch address and two literal address comparators.
If a match occurs, the address is remapped to an address in system memory, defined by the
FPB_REMAPR register plus an offset corresponding to the matching comparator.
Alternatively, the instruction comparators can be configured to generate a breakpoint
instruction.
38.9.1

FPB control register (FPB_CTRLR)

Address offset: 0x000
Reset value: 0x0000 0260
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
NUM_ NUM_
NUM_
Res. CODE CODE
CODE
5 4
6
r r
Bits 31:15 Reserved, must be kept at reset value.
Bits 11:8 NUM_LIT[3:0]: number of literal address comparators supported (read only)
0x2: Two literal comparators supported.
Bits 14, 13, 12, 7, 6, NUM_CODE[6:0]: number of instruction address comparators supported - least significant bits
5, 4 (read only)
0x6: 6 instruction comparators supported
Bits 3:2 Reserved, must be kept at reset value.
Bit 1 KEY: write protect key
A write to FPB_CTRLR register is ignored if this bit is not set to 1.
Bit 0 ENABLE: FPB enable
0: Disabled
1: Enabled
