Parameter Descriptions
36-60 Terminal X49/11 Analogue Output
Select the functionality of terminal X49/11.
Option:
[141] Bus ctrl 0-20mA t.o.
36-62 Terminal X49/11 Min. Scale
Range: Function:
0 % [0 - Match the minimum output of terminal
*
200 %] X49/11 with a required value. For more
information, see parameter 36-42 Terminal
X49/7 Min. Scale.
36-63 Terminal X49/11 Max. Scale
Range: Function:
100 % [0 - Scale the maximum output of terminal
*
200 %] X49/11. For more information, see
parameter 36-43 Terminal X49/7 Max. Scale.
36-64 Terminal X49/11 Bus Control
Range: Function:
0 % [0 - 100 %] This parameter contains the output level of
*
terminal X49/11 if the terminal is controlled
by a fieldbus.
36-65 Terminal X49/11 Timeout Preset
Range: Function:
0 % [0 - 100 %] The frequency converter sends the value of
*
this parameter to the output terminal when
the terminal is controlled by a fieldbus and a
timeout is detected.

3.29 Parameters: 40-** Special Settings

40-40 Fault Log: Ext. Reference
Range:
0 % [-200 - 200 %]
*
40-41 Fault Log: Frequency
Range:
0 Hz [0 - 6500 Hz]
*
40-42 Fault Log: Current
Range:
0 A [0 - 10000 A]
*
40-43 Fault Log: Voltage
Range:
0 V [0 - 6000 V]
*
40-44 Fault Log: DC Link Voltage
Range:
0 V [0 - 10000 V]
*
MG33MP02
Programming Guide
40-45 Fault Log: Control Word
Range:
Function: 0
*
40-46 Fault Log: Status Word
Range:
0
*
3.29.1 40-5* Advanced Control Settings
Parameters for configuring the advanced motor control
settings.
40-50 Flux Sensorless Model Shift
Use this parameter to enable or disable the shifting between flux
model 1 and flux model 2 at low speed. See also
parameter 1-66 Min. Current at Low Speed.
Option:
[0]
[1]
40-51 Flux Sensorless Corr. Gain
Range:
Size related

3.30 Parameters: 42-** Safety Functions

The parameters in this parameter group are available when
a safety option is installed in the frequency converter. For
information about the safety-related parameters, see the
operating instructions for the safety options:
•
•
42-37 Level 1 Password Buffer
Function:
Range:
Size related
42-87 Time Until Manual Test
Function:
Range:
8761 h
3.31 Parameters: 43-** Unit Readouts
Function:
The parameters in this group provide readouts for
monitoring the operation of frequency converters in the
D–F enclosure sizes.
Function:

3.31.1 43-0* Component Status

This parameter group contains read-only information on
Function:
hardware components in the power section. All parameters
in this group are arrays:
Danfoss A/S © 10/2018 All rights reserved.
[0 - 65535 ]
[0 - 65535 ]
Off
On
[0.1 - 200.0 ]
*
®
VLT Safety Option MCB 150/151 Operating
Instructions.
®
VLT Safety Option MCB 152 Operating Instructions.
[0 - 8 ]
*
[0 - 8761 h]
*
Function:
