Icom VE-PG4 Operating Manual page 266

10
IP LInE SEttIngS
VoIP Phonebook screen
IP Line Settings > VoIP Phonebook
■ Save or Write the VoIP Phonebook
 About the rules of a CSV file for the VoIP phonebook
When editing a saved CSV file, be sure to observe the following rules. Otherwise the VoIP phonebook
settings may not load properly into the RoIP gateway.
Column Title
A Index
B name
C Phone number
D SIP URI
E --
• the lines that begins with "#" are comments.
• Delete unnecessary lines.
1 ~ 1000
Do not duplicate the number.
Up to 30 characters
"tel:" and up to 31 digits (0~9, #,*)
Enter either of the following format, up to 63 characters
sip:[SIP user name]@[Destination IP address]
sip:[SIP user name]@[Destination host name or domain name]
Fixed to "voip"
10-9
Description
