Icom VE-PG4 Installation Manual

Usb driver installation
Hide thumbs Also See for VE-PG4:
1
2
3
4
5
6
7
Table of Contents

Advertisement

Quick Links

Download this manual
You can set up an Icom network device using a PC, by connecting it to the [CONSOLE] port of the network
device through a USB (Mini-B) cable.
Read this installation guide and install the USB driver to your PC, before connecting the USB cable.
This guide describes based on the following conditions:
• You have already downloaded the latest USB driver from the Icom Download Service website.
http://www.icom.co.jp/world/support/
• The Icom network device that you want to set up has a [CONSOLE] port.
• The operating system of the PC is Windows 10.
L The installation steps or displayed dialog may differ, depending on the operating system.

TABLE OF CONTENTS

1. OVERVIEW ............................................................ 1
System requirements ......................................... 1
2. PRECAUTIONS ..................................................... 2
Before the installation ........................................ 2
Before connecting to a PC ................................. 2
After the installation ........................................... 2
3. INSTALLING THE DRIVER .................................. 3
1.

OVERVIEW

System requirements

The following hardware and software are required:
PC
• Microsoft
Windows
10 (32/64 bit)
®
®
• Microsoft
Windows
8.1 (32/64 bit)*
®
®
*Except for the "RT" version.
• Microsoft
Windows
7 (32/64 bit)
®
®
• A USB 1.1, 2.0, or 3.0 port
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom,
Germany, France, Spain, Russia, Australia, New Zealand, and/or other countries.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries.
All other products or brands are registered trademarks or trademarks of their respective holders.
USB DRIVER
INSTALLATION GUIDE
4. FOR YOUR REFERENCE ..................................... 5
Cable
• A USB cable (User supplied)
NOTE:
• Depending on the length of a third-party USB
• Depending on the network device, the
1
4-1 Terminal software setting ............................. 5
4-2 COM Port setting ......................................... 6
4-3 Uninstalling the driver .................................. 7
Mini-B
cable, the network device may not work correctly
even if the PC recognizes it. Use a cable as short
as possible.
[CONSOLE] port shape may differ. Purchase a
proper USB cable.
For the Icom
network devices
Type A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VE-PG4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Icom VE-PG4

Summary of Contents for Icom VE-PG4

  • Page 1: Table Of Contents

    [CONSOLE] port shape may differ. Purchase a proper USB cable. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia, Australia, New Zealand, and/or other countries.

  • Page 2: Precautions

    USB cable. latest driver. • Directly connect the network device and the PC. See “Uninstalling the driver” on page 7 for Icom is not responsible for improper operation details. when connecting them through a USB hub. After the installation •...

  • Page 3: Installing The Driver

    INSTALLING THE DRIVER NOTE: • NEVER connect the USB cable between the network device and the PC until the USB driver has been installed. Disconnect the cable, if connected, before starting the USB driver installation. • This USB driver does not support the automatic recognition system. L The displayed dialog, indications, or operations 6.
  • Page 4 Click 13. Double-click “Ports (COM & LPT)” on the “Device IMPORTANT: Directly connect the network Manager” screen. device and the PC. Icom is not responsible for improper operation when connecting them Double-click through a USB hub. 9. The installation icon is displayed on the taskbar as shown below, and then Windows starts installing the driver.

  • Page 5: For Your Reference

    Network device • The login prompt with the device name is To the [CONSOLE] port displayed. (For example: “VE-PG4> login:”) L After you have successfully logged in to the device, you can display the available command list by pressing the [Tab] key.

  • Page 6: Com Port Setting

    4. FOR YOUR REFERENCE 4-2 COM Port setting To change the COM Port number setting after you have installed the USB driver, connect the network device to the PC first, and then turn ON the device. 1. Click the folder icon on the taskbar. 5.

  • Page 7: Uninstalling The Driver

    3. Click “Windows Driver Package - Silicon Laboratories Inc. (silabser) Ports.” Click 4. Click <Uninstall>. • When the “User Account Control” dialog is displayed, click <Continue>. Click 5. Follow the instructions on the screen to uninstall. Apr. 2019 A7522-1EX © 2019 Icom Inc.
