TX Matrix Plus Quick Start Description
Step 1: Prepare the Site
TX Matrix Plus Rack-Mounting Requirements
Copyright © 2015, Juniper Networks, Inc.
This Quick Start contains information you need to install and configure the TX Matrix
Plus Router quickly. For complete installation instructions, see the TX Matrix Plus Router
Hardware Guide at
http://www.juniper.net/techpubs/hardware/
WARNING:
This Quick Start contains a summary of safety warnings in
Matrix Plus Safety Warnings" on page
this router, including translations, see the TX Matrix Plus Router Hardware
Guide at
http://www.juniper.net/techpubs/hardware/
The TX Matrix Plus router is a modular, rack-mountable system. One TX Matrix Plus
router can be installed in one standard 23-in. wide, 78-in. high, EIA telco rack. The TX
Matrix Plus router is shipped in a wooden crate. A wooden pallet forms the base of the
crate. TheTX Matrix Plus chassis is bolted to this pallet. The shipping crate contains:
One accessory box (the box to which this Quick Start is taped)
One Juniper Networks TX Matrix Plus router
One Quick Start (this document)
One tool kit
Mounting hardware
Cable management system
TX Matrix Plus Rack-Mounting Requirements on page 3
Tools Required to Install the TX Matrix Plus Router on page 4
The TX Matrix Plus router can be installed in many types of racks. Follow these guidelines:
The rack rails must be spaced widely enough to accommodate the TX Matrix Plus
router chassis's external dimensions: 52.0 in. (132.1 cm) high, 36.2 in. (91.9 cm) deep,
and 21.4 in. (54.4 cm) wide. The center-mounting brackets and front-mounting flanges
extend the width to 23 in. (58.4 cm) racks.
If the horizontal spacing between the rails is wider than the center-mounting brackets
or front-mounting flanges, use approved wing devices to narrow the opening between
the rails as required.
The rack must be strong enough to support the weight of the fully configured TX Matrix
Plus router, up to 925 lb (420 kg).
We recommend that you install one TX Matrix Plus router in its own dedicated rack.
TX Matrix Plus Quick Start Description
.
