Draytek Vigor2762 series User Manual page 630

Syntax Description Syntax Description
Parameter
<WAN interface number>
<MRU size >
Example
Example
>
wan ppp_mru 1 ?
% Now: 1492
> wan ppp_mru 1 1490
>
> wan ppp_mru 1 ?
% Now: 1490
> wan ppp_mru 1 1492
> wan ppp_mru 1 ?
% Now: 1492
Telnet Command:
Telnet Command:
This command allows users to adjust the size of MTU/MTU2 for WAN.
wan mtu [value]
wan mtu2 [value]
Syntax Description
Syntax Description
Parameter
value
Example
Example
> wan mtu 1100
> wan mtu ?
Static IP/DHCP (Max MSS: 1500)
PPPoE(Max MSS: 1492)
PPTP/L2TP(Max MSS: 1460)
% wan ppp_mss <MSS size: 1000 ~ 1500>
% Now: 1100
Telnet Command:
Telnet Command:
This command allows you to enable or disable the function of DF (Don't fragment)
wan DF_check [on]
wan DF_check [off]
Syntax Description
Syntax Description
Parameter
620
Description
Type a number to represent the physical interface. For Vigor130,
the number is 1 (which means WAN1).
It means the number of PPP LCP MRU. The available range is from
1400 to 1600.
wan mtu /wan mtu2
wan mtu /wan mtu2
Description
It means the number of MTU for PPP. The available range is from
1000 to 1500.
For Static IP/DHCP, the maximum number will be 1500.
For PPPoE, the maximum number will be 1492.
For PPTP/L2TP, the maximum number will be 1460.
wan DF_check
wan DF_check
Description
Vigor2762 Series User's Guide
