Draytek Vigor2762 series User Manual page 556

-p <proto>
-b 1/0
-M enable/disable
-v
-c
ppa n – used in QoS or specific host
-l <rule>
-h <host>
-s <start port>
-e <end port>
Example
Example
> ppa -m 1 -p 1 -b 0
Set ok! The PPA mode is Auto
% You need to set the Manual mode first !
%TWO way accleration is disable
> ppa -v
% PPA mode is Auto
%PPA Protocol TCP 1, UDP 0
%PPA two way disable
%PPA time
%PPA range is 192
%PPA LAN entries 0
%PPA WAN entries 0
546
2=manual(traffic)
3=manual(qos)
4=manual(specific hosts)
0=disable
Specify a protocol.
proto - 1-TCP; 2-UDP; 3-Both.
Enable/disable TWO-way hardware acceleration.
Enable/disable the multicast hardware acceleration.
Show PPA_WAN_Table and PPA_LAN_Table for reference.
Clean all settings.
Specify an index number of rule profile for QoS mode.
Type an IP address for Specific Host mode.
Specify a starting port number for Specific Host mode.
Specify an ending port number for Specific Host mode
is 10
Vigor2762 Series User's Guide
