Network structures
6.1 VLAN
Further notes
You assign the VLAN a name with the command name.
6.1.4.3

ports

Description
With this command, you generate a list that specifies the behavior of the interfaces and
replaces the existing VLAN configuration.
● Member Port (tagged port)
The interface is added permanently to the list of incoming and outgoing connections.
Tagged and untagged frames are transferred.
● Untagged Port
The interface transfers untagged frames. If the VLAN ID (PVID) is set, incoming untagged
frames are given a tag with the VLAN ID specified there. Received frames with a VLAN ID
are forwarded according to the VLAN ID. With outgoing frames, the tag with the VLAN ID
is removed.
● Forbidden Ports
The "tagged port" and "untagged port" you specify with this command are used for outgoing
data traffic.
Requirement
You are in the VLAN configuration mode.
The command prompt is as follows:
cli(config-vlan-$$$)#
Syntax
Call up the command with the following parameters:
ports
194
This interface is not used for communication in a VLAN.
(
[<interface-type><0/a-b,0/c,...>]
[<interface-type><0/a-b,0/c,...>]
[port-channel<a,b,c-d>]
)
[
untagged<interface-type> <0/a-b,0/c,...>
(
[<interface-type><0/a-b,0/c,...>]
[port-channel <a,b,c-d>]
[all]
)
]
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
Configuration Manual, 07/2017, C79000-G8976-C361-06
