5 Specifications and Dimensional Drawings of Cables and Peripheral Devices

5.8.4 Connector Terminal Block Converter Unit

5.8.4 Connector Terminal Block Converter Unit
(1) Model: JUSP-TA50P
The connection between the connector terminal block converter and the SERVOPACK is shown below.
YA KAWA
ERVOPACK
CN1
1
1
19
33
1
2
(2) Dimensional Drawings of Terminal Block
Units: mm (in)
Terminal
block (50P)
7 (0.28)
M3.5 screw
1
1
2
2×φ3.5 (φ0.14)
3.5 (0.14)
Can be fixed on DIN rail
(3) Dimensional Drawing of Cable
Units: mm (in)
SERVOPACK end connector (50P)
10150-6000EL (Sumitomo 3M Ltd.)
Shell
10350-52AO-008 (Sumitomo 3M Ltd.)
500
5-60
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
+50
mm (19.69
Attached cable length: 500
-0
Connector terminal block converter unit
model: JU P-TA50P
16
32
50
49
50
Connector plug (50P)
7 (0.28)
MR-50RMD2
1 16
19 32
33 50
49
50
247.5 (9.74)
Cable (black)
AWG#28 25P
UL20276 VW-1SC
+50
+1.97
(19.69 )
0
0
+1.97 in)
0
2×M3 tapped holes
3.5 (0.14)
3.5 (0.14)
With terminal block
cover removed
Connector terminal block converter unit
end connector (50P)
MRP-50F01 (Honda Tsushin Kogyo Co., Ltd.)
Case
MR-50L (Honda Tsushin Kogyo Co., Ltd.)
247.5 (9.74) 3.5 (0.14)
