YASKAWA SGM H Series User Manual page 230

SGMSH-
Specifi-
cations
10 15 20 30 40 50
45 (1.77)
LR
40 (1.57)
Q
32 (1.26)
QK
0
24
– 0.013
S
– 0.0001
 
Straight,

0.945
 

– 0.0006
6
with key
and tap
8 (0.31)
W
7 (0.28)
T
4 (0.16)
U
M8 screw, depth: 16
P
* 1. If the SGMGH-05A and 09A are not specified as the mounting interchangeable type, the value of the
QK will be 16 (0.629).
* 2. If the SGMGH-05A and 09A are not specified as the mounting interchangeable type, the value of the
T will be 2 (0.078).
* 3. If the SGMGH-05A and 09A are not specified as the mounting interchangeable type, the value of the
U will be 4.5 (0.177).
