Lubrication
INFO
• Oil lubricating type (frame numbers: 4130 to 4190)
Servomotors of this type have been shipped with oil removed. Be sure to supply oil until the red line at the upper side
of the oil guage.
Lubrication oil recommended is industrial-use extreme-pressure gear oil of SP-system, JIS K 2219 industrial-use gear
oil or equivalent. Refer to the following table.
Ambient
Temperature
0 to 35 °C
(32 to 95 °F)
The following shows approximate oil amount to be supplied.
Frame No.
Horizontal
type
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Manufacturer
COSMO Oil Co., Ltd. Nippon Oil Co., Ltd.
COSMO Gear BON-NOCK
SE M
100, 150 100, 150
4130 4160
4145 4155
4135 4165
0.7 0.7 0.7
3.15 Dimensional Drawings of SGMGH Servomotors (1500 min
Tonen General
Sekiyu K. K.
GENERAL SP
Gear Roll
100, 150
Units: liter
4170 4180
4190
4175 4185
1.4 1.9 2.5 4.0
-1
)
3
3-113
