5.1.4 Flexible Cables for SGMAH and SGMPH Servomotors With Brakes

SERVOPACK end
(10) (0.39)
8.5 (0.33)
M4 crimped
terminals
Wire markers
Applicable Servomotor
Models
SGMAH
200 V: 30 to 750 W
100 V: 30 to 200 W
SGMPH
200 V: 100 to 750 W
100 V: 100 W and 200 W
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
5.1 Specifications and Dimensional Drawings of Servomotor Main Circuit Cable
50 (1.97) L
Finished dimension
φ7.0 (φ0.28)
Heat-shrinkable tube
Cap: 350781-1 (6-pin)
Socket: 350536-6 (Chained)
Units: m (ft)
Cable Type
JZSP-CMM11-03
JZSP-CMM11-05
JZSP-CMM11-10
JZSP-CMM11-15
JZSP-CMM11-20
Servomotor end
35 (1.38)
Cable
Length
(L)
3
(9.84)
5
(16.40)
10
(32.81)
15
(49.21)
20
(65.62)
Units: mm (in)
5-5
