YASKAWA SGM H Series User Manual page 595

Parameter
No.
Pn40A
First Stage Notch Filter Q Value
Pn40B
Second Stage Notch Filter Frequency
Pn40C
Second Stage Notch Filter Q Value
Pn500
Positioning Completed Width
Pn501 Zero Clamp Level
Pn502 Rotation Detection Level
Pn503
Speed Coincidence Signal Output Width
Pn504 NEAR Signal Width
Pn505 Overflow Level
Pn506 Brake Reference - Servo OFF Delay Time
Pn507 Brake Reference Output Speed Level
Pn508 Timing for Brake Reference Output during
Motor Operation
Pn509 Momentary Hold time
* Used only when the software version number is later than 32.
