YASKAWA SGM H Series User Manual page 63

2 Selections
2.5.2 Cables for SGMGH/SGMSH/SGMDH Servomotors
Name
Flexible type
cable with
connectors at both
ends
CN2
Encoder
Cables
(Cont'd)
* Applicable for
every type
and capacity.
Flexible type
cable with
loose wire at
encoder end
Servomotor
Main Circuit
Cables and connectors
Cables and
Connectors
Note: When using the cable for the moving section such as robots, use a flexible type cable. For the safety precau-
tions, see 5.7 I/O Signal Cables for CN1 Connector.
2-26
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Length Type
3m
JZSP-CMP11-03
(9.84 ft)
5 m
JZSP-CMP11-05
(16.4 ft)
10 m
JZSP-CMP11-10
(32.8 ft)
15 m
JZSP-CMP11-15
(49.2 ft)
20 m
JZSP-CMP11-20
(65.6 ft)
3m
JZSP-CMP12-03
(9.84 ft)
5 m
JZSP-CMP12-05
(16.4 ft)
10 m
JZSP-CMP12-10
(32.8 ft)
15 m
JZSP-CMP12-15
(49.2 ft)
20 m
JZSP-CMP12-20
(65.6 ft)
3m
JZSP-CMP13-03
(9.84 ft)
5 m
JZSP-CMP13-05
(16.4 ft)
10 m
JZSP-CMP13-10
(32.8 ft)
15 m
JZSP-CMP13-15
(49.2 ft)
20 m
JZSP-CMP13-20
(65.6 ft)
Specifications
With a straight plug
SERVOPACK Encoder
end end
With an L-shaped plug
SERVOPACK Encoder
end end
L
SERVOPACK Encoder
end end
Cables with connectors are not avail-
able. Refer to Chapter 5 Specifica-
tions and Dimensional Drawings of
Cables and Peripheral Devices.
Refer-
ence
5.4.6
−
