6.3 Examples of I/O Signal Connections

6.3.1 Speed Control Mode

Speed reference
±
(±
2 to 10V
/rated motor
speed)
∗ 4.
External torque
limit/Torque feed
forward
± ±
( 1 to 10 V
/rated torque)
Backup battery
(2.8 to 4.5 V)
∗ 3.
SEN signal input
Servo ON
(Servo ON when ON)
P control
(P control when ON)
Forward run prohibited
(Prohibited when OFF)
Reverse run prohibited
(Prohibited when OFF)
Alarm reset
(Reset when ON)
Forward current limit
(Limit when ON)
Reverse current limit
(Limit when ON)
* 1. represents twisted-pair wires.
* 2. The time constant for the primary filter is 47 µs.
* 3. Connect a backup battery when using an absolute encoder. When connecting a battery to the host controller,
however, do not connect a backup battery.
* 4. Enabled by the parameter setting.
* 5. Customers must purchase a 24 VDC power supply with double-shielded enclosure.
* 6. Enabled when using the absolute encoder.
Note: The functions allocated to the input signals SI0 to SI6 and the output signals SO1 to SO3 can be changed by
using the parameters. Refer to 7.3.2 Input Circuit Signal Allocation and 7.3.3 Output Circuit Signal Alloca-
tion.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
SERVOPACK
∗ 1.
∗ 2.
V-REF 5
LPF
SG 6
∗ 2.
T-REF 9
LPF
10
SG
BAT (+)
21
∗ 3.
BAT (-)
22
SEN 4
+5 V
2
SG
0 V
∗ 5.
3.3 kΩ
+24 V +24VIN 47
40
/S-ON (SI0)
41
/P-CON
(SI1)
42
P-OT (SI2)
43
N-OT (SI3)
44
/ALM-RST (SI4)
45
(SI5)
/P-CL
46
/N-CL (SI6)
6.3 Examples of I/O Signal Connections
37 ALO1
Alarm code output
A / D
Max. operating voltage:
38 ALO2
30 VDC
Max. operating current:
39 ALO3
20 mA DC
33
PAO
34
/PAO
PG dividing ratio output
35
PBO
Applicable line receiver
/PBO
36
19
PCO
20 /PCO
Amount of phase-S rotation
∗ 6.
Serial data output
48 PSO
Applicable line receiver
49 /PSO
SN75175 manufactured
by Texas Instruments or
the equivalent corresponding
to MC3486
SG
1
(SO1)
/V-CMP+
25
26 /V-CMP-
(SO2)
/TGON+
27
/TGON-
28
(SO3)
29 /S-RDY+
30 /S-RDY-
31 ALM+
Servo alarm output
(OFF for an alarm)
32
ALM-
Photocoupler output
Max. operating voltage:
Connector
30 VDC
shell
Max. operating current:
FG
50 mA DC
Connect shield to
connector shell.
SN75175 manufactured
by Texas Instruments or
the equivalent corresponding
to MC3486
Speed coincidence detection
(ON when speed coincides.)
Running output
(ON when the motor speed
exceeds the settings.)
Servo ready output
(ON when ready)
6
6-9
