9 Adjustments

9.5 Analog Monitor

Signals for analog voltage references can be monitored.
To monitor analog signals, connect the analog monitor cable (JZSP-CA01 or DE9404559) to the connector CN5.
The analog monitor signals can be selected by setting parameters Pn003.0 and Pn003.1.
For 30W to 5.0 kW SERVOPACK
Pin Number
1
2
3, 4
9-28
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
CN5
Cable Type:
JZSP-CA01
or DE9404559
Line Color Signal Name
Red
Analog monitor 2
White
Analog monitor 1
Black (2 lines)
GND (0 V)
SERVOPARK 200V
SGDM-
Ver.
YASKAWA
Black
Black
White
For 6.0 to 15.0 kW SERVOPACK
Red
Monitoring Item with Factory Setting
-1
Motor speed: 1 V/1000 min
Torque reference: 1 V/100% rated torque
−
POWER
BATTERY
MODE/SET DATA/
CN5
