12.3.2 List of Parameters
Parameter
No.
Pn304 JOG Speed
Pn305 Soft Start Acceleration Time
Pn306 Soft Start Deceleration Time
Pn307
Speed Reference Filter Time Constant
Pn308 Speed Feedback Filter Time Constant
Pn309
Reserved (Do not change)
Pn400 Torque Reference Input Gain
Pn401 Torque Reference Filter Time Constant
Pn402 Forward Torque Limit
Pn403
Reverse Torque Limit
Pn404 Forward External Torque Limit
Pn405
Reverse External Torque Limit
Pn406 Emergency Stop Torque
Pn407
Speed Limit during Torque Control
Pn408
Torque Function Switches
4th
3rd
digit
digit
n.
Pn409 First Stage Notch Filter Frequency
* 1. Used only when the software version number is later than 32.
* 2. The factory setting is 0001 for the models with 5 kW or more.
* 3. The factory setting is 1500 for the models with 5 kW or more.
