4.1 SERVOPACK Ratings and Specifications

• Take appropriate measures to ensure that the input power supply is supplied within the specified voltage
range.
An incorrect input power supply may result in damage to the SERVOPACK. If the voltage exceeds these values, use
a step-down transformer so that the voltage will be within the specified range.
4.1.1 Single-phase 100 V
The value of the input power supply voltage is maximum 127 Vrms.
SERVOPACK Model SGDM-
Max. Applicable Servomotor
Capacity (kW)
Continuous Output Current (A
Max. Output Current (A
Input Power
Supply
Configuration
Regenerative Processing
4.1.2 Single-phase/Three-phase 200 V
The value of the input power supply voltage is maximum 253 Vrms.
SERVOPACK
A3A A5A 01A 02A 04A 05A 08A 10A 15A 20A 30A 50A 60A 75A 1AA 1EA
Model SGDM-
Max. Applicable
0.03 0.05
Servomotor
Capacity (kW)
Continuous Out-
put Current
0.44 0.64 0.91
(A )
rms
Max. Output Cur-
1.3
rent (A )
rms
Main
Single-phase/Three-phase 200 to 230 VAC +10 to -15%, 50/60 Hz
Input
Circuit
Power
Control
Supply Single-phase 200 to 230 VAC +10 to -15%, 50/60 Hz
Circuit
Configuration Base-mounted (Rack mounting available as an option)
Regenerative
External regenerative resistor
Processing
