YASKAWA SGM H Series User Manual page 56

Name
Cable with connec-
tors at both ends
Cable with loose
wire at encoder
end
CN2
Encoder
Cable
Flexible type
cable with connec-
tors at both ends
Flexible type
cable with loose
wire at encoder
end
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Length Type
3 m
JZSP-CMP00-03
(9.84 ft)
5 m
JZSP-CMP00-05
(16.4 ft)
10 m
JZSP-CMP00-10
(32.8 ft)
15 m
JZSP-CMP00-15
(49.2 ft)
20 m
JZSP-CMP00-20
(65.6 ft)
3 m
JZSP-CMP03-03
(9.84 ft)
5 m
JZSP-CMP03-05
(16.4 ft)
10 m
JZSP-CMP03-10
(32.8 ft)
15 m
JZSP-CMP03-15
(49.2 ft)
20 m
JZSP-CMP03-20
(65.6 ft)
3 m
JZSP-CMP10-03
(9.84 ft)
5 m
JZSP-CMP10-05
(16.4 ft)
10 m
JZSP-CMP10-10
(32.8 ft)
15 m
JZSP-CMP10-15
(49.2 ft)
20 m
JZSP-CMP10-20
(65.6 ft)
3 m
JZSP-CMP13-03
(9.84 ft)
5 m
JZSP-CMP13-05
(16.4 ft)
10 m
JZSP-CMP13-10
(32.8 ft)
15 m
JZSP-CMP13-15
(49.2 ft)
20 m
JZSP-CMP13-20
(65.6 ft)
2.5 Selecting Cables
Specifications
SERVOPACK Encoder
end end
SERVOPACK Encoder
end end
Encoder
SERVOPACK
end
end
SERVOPACK Encoder
end end
Refer-
ence
5.4.1
2
5.4.3
5.4.5
2-19
