4 SERVOPACK Specifications and Dimensional Drawings

4.7.8 Three-phase 200 V: 11.0 kW/15.0 kW (1AADA to 1EADA)

4.7.8 Three-phase 200 V: 11.0 kW/15.0 kW (1AADA to 1EADA)
SERVOPACK 200V
SGDM-
1AADA
Ver.
YASKAWA
Control circuit
140 (5.51)
terminal M4
Regenerative
resistor
terminal M6
CHARGE
B1 B2
L1C L2C
160 (6.30)
L1 L2 L3
34 27 (1.06)
(1.34)
151 (5.94)
30
200 (7.87)
(1.18) 260 (10.24)
View A
External Terminal Connector
Main circuit
power supply
L1 L2 L3
Three-phase
200 VAC
50/60 Hz
4-24
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
CN3 CN8
POWER
MODE/SET DATA/ BATTERY
CN5
CN1 CN2
46 (1.81)
+1 - U V W
45
7
(1.77)
(0.28)
(1.34)
30 (1.18)*
Ground
Main circuit
terminal M8
terminal M8
A
External
Control power
regenerative
supply
resistor
L1C L2C B1 B2
Single-phase
200 VAC
50/60 Hz
Cooling fan
10 (0.39)
Nameplate
17 (0.67)
34
126 (4.96) 125 (4.92)
285 (11.22)
Ground
Main circuit
terminal M8
terminal M8
* Reference length
Units: mm (in)
Approx. mass: 26 kg (57.32 lb)
SERVOPACK Connector
Connector SERVOPACK
Symbol Connector Model
CN1
10250-52A2JL
CN2
53460-0611
CN3
10214-52A2JL
200 (7.87)
30
(1.18)
Manufacturer
Sumitomo 3M Co., Ltd.
Molex Japan Co., Ltd.
Sumitomo 3M Co., Ltd.
30
(1.18)*
