3.19.5 SGMCS Servomotors φ280 Model
6 (0.24)
1.5
(0.059)
(Rotating
Section)
Rotating
Section
Rotating Section
(shown with hatching)
Model
SGMCS-
141 (5.55)
45M A11
191 (7.52)
80M A11
241 (9.48)
1AM A11
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
LL 15 (0.59)
KB2
0.08 (0.003) A B
KB1
15 (0.59)
(within φ280h7)
5 A
(0.20)
Rotating Section
(shown with
hatching)
15 (0.59)
(within φ75H6)
B
0.04 (0.001)
LL KB1
87.5 (3.44) 122 (4.80)
137.5 (5.41) 172 (6.77)
187.5 (7.38) 222 (8.74)
3.19 Dimensional Drawings of SGMCS Servomotors
φ0.08
A B
(0.003)
0.04
(0.001)
0
φ280h7: φ280
-0.052
+0.019
φ75H6: φ75
0
0
φ110h7: φ110
-0.035
Approx. Mass
KB2
kg (lb)
38 (83.77)
45 (99.20)
51 (112.4)
12 × M6 screw, depth 15 (0.59)
41 (1.61)
12 × M6 screw, depth 18 (0.71)
+0.0006
(φ11.023 )
-0.0014
∗
Reference length
Units: mm (in)
+0.0005
(φ2.953 )
-0.0002
+0.0007
(φ4.33 )
-0.0007
3-153
