Sgmgh Servomotor; European Safety Standards - YASKAWA SGM H Series User Manual

5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.2.9 SGMGH Servomotor (1000 min
5.2.9 SGMGH Servomotor (1000 min

European Safety Standards

(1) Servomotors Without Holding Brakes
(a) For 0.3 to 3.0 kW Servomotors
Select a cable clamp in accordance with the applied cable diameter.
The straight plug type JA06A-22-22S-J1-EB and L-shaped plug type JA08A-22-22S-J1-EB conform to IP67 Protective
INFO
Construction Standard only.
Capacity Connector on
(kW) Servomotor
0.3
CE05-2A18-10PD-B
0.6
0.9
1.2
JL04HV-2E22-22PE-B
2.0
3.0
(b) For 4.0 kW and 5.5 kW Servomotors
Select a conduit in accordance with the applied cable diameter.
Capacity Connector on
(kW) Servomotor
4.0
JL04V-2E32-17PE-B
5.5
5-22
