ABB i-bus
KNX
Parameters
Week page
Program the weekly switching times from Monday to Sunday on the Week page.
Click the day of the week to be programmed to select it; further information on the switching times is then
displayed.
Set the switching times by dragging the related switching command from the action bar
time on the selected day (drag & drop).
You can enter any temperature in the range from -20.0 °C to 150.0 °C.
You can add as many switching times as necessary. The minimum spacing between two switching
commands is 15 minutes. The end time for a switching command is the start time for the next command. A
switching command applies to the end of the day as a maximum, the switching command on the next day
then becomes active.
You can adjust the start time for a switching command by dragging the circle horizontally or by clicking the
+ / - buttons beside the circle.
You adjust the temperature for a switching command by dragging the circle on the left or by clicking the
+ / - buttons beside the circle.
You can copy the switching times on one day to another day by dragging the Copy
day to the destination day (drag & drop). All existing switching times on the destination day are overwritten
by this process.
Click the trash bin
After this action you can program a specific switching pattern for each day of the week. The switching
patterns for a day of the week are applied to each corresponding day of the week, i.e. a switching pattern
that has been set, e.g., for a Tuesday applies to all subsequent Tuesdays in the future.
beside the selected day of the week to delete all switching times on that day.
to the required
icon for the original
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 437
