CHAPTER 5 SERVICE MODE

3. I/O (I/O display mode)

The following screen appears in response to COPIER>I/O; for the items, see the pages
that follow:
DC-CON
R-CON
FEEDER
SORTER
MN-CONT
<Guide to the Screen>
5-20 T
Input/output port of DC controller PCB
Input/output port of reader controller PCB
Input/output port of ADF controller PCB
Input/output port of finisher controller PCB
Input/output port of main controller PCB
F05-301-01
P001 xxxxxxxxxxxxxxxx
COPYRIGHT © 2001 CANON INC.
bit 0
bit 15
address
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
