<AE>
Executing AE Adjustment
If you have cleared the RAM on the reader controller PCB, enter the settings indicated on
the service label.
AE-TBL
Use it to adjust the density of characters for image density adjustment.
Range of 1 to 9 Default: 5
adjustment
COPYRIGHT © 2001 CANON INC.
Copy density
White
A higher setting increases text density.
A lower setting decreases text density.
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
White
F05-401-02
COPIER>ADJUST
Original density
5-45 T
