Level 3 Screen - Canon Image Reader-A1 iR5000i Service Manual

1.5.3 Level 3 Screen

DC-CON
Level 2 item
R-CON
PANEL
FEEDER
SORTER
Level 3 item
NIB
PS/PCL
LIPS
To go back to previous page
ADJ-X
COPYRIGHT © 2001 CANON INC.
< 1/2 >
<VERSION>
To go to next page
F05-105-03
Switches between + and -
Stop
key: stops the ongoing operation.
Clear key: clears a value.
Start key: makes copies without ending service mode.
F05-105-04
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
Page number
< READY >
ready to accept a servicing/
READY:
copying operation.
paper jam exists.
JAM:
service operation under way.
SERVICE:
initial rotation or the like under
WAITING:
way.
door open.
DOOR:
copying under way.
COPYING:
error exists.
ERROR:
toner absent
NO-TONER:
full of waste toner.
WTNR-FUL:
+/-
OK
Accepts input value
5-5 T
