CHAPTER 4 IMAGE FORMATION SYSTEM
COPIER>OPTION>BODY>TR-SP-C1
(Use it to switch the transfer/separation output value for pickup from the
right deck.)
COPIER>OPTION>BODY>TR-SP-C2
(Use it to switch the transfer/separation output for pickup from the left
deck.)
COPIER>OPTION>BODY>TR-SP-C3
(Use it to switch the transfer/separation output value for pickup from the
cassette 3.)
COPIER>OPTION>BODY>TR-SP-C4
(Use it to switch the transfer/separation output value for pickup from the
cassette 4.)
COPIER>OPTION>BODY>TR-SP-MF
(Use it to switch the transfer/separation output for pickup from the manual
feed tray.)
COPIER>OPTION>BODY>TR-SP-DK
(Use it to switch the transfer/separation output for pickup from the side pa-
per deck.)
The transfer/separation output value is switched for pick up from each re-
spective source of paper with the aim of responding to various problems:
0: normal (default)
1: prevents double transfer
2: prevents separation faults
3: prevents transfer faults
4-31 P
