1. Organization of Service Mode

1.1 Outline

The screens in service mode are grouped into three: Initial screen, Level 1/Level 2 screen,
and Level 3 screen.
User screen
( )(2,8)( )
Reset key
Initial screen
Select an item.
Level 1/Level 2
screen
Select a Level 1 item at the top of the screen.
Select a Level 2 item from the list.
Level 3 screen
COPYRIGHT © 2001 CANON INC.
Reset key
From Level 1/
Level 2 screen
Level 3 screen
Preceding/
Following page
2000 2000 2000 2000
Level 3 screen
Preceding/
Following page
F05-101-01
CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
Level 3 screen
Preceding/
Following page
5-1 T
