Canon Image Reader-A1 iR5000i Service Manual page 531

2) Loosen the four screws [3], and detach
the front cover [4] to the front.
When mounting the front cover
to the deck, be sure to match it
against the coupling for the pa-
per level indicator.
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 8 PAPER DECK
[3]
[4]
F08-301-03
Match.
F08-301-04
8-21 P
