Canon Image Reader-A1 iR5000i Service Manual page 469

[1] Manual feed pickup drive clutch (CL3)
[2] Main motor (M2)
[3] Developing clutch (CL1)
[4] Drum motor (M1)
[5] Waste toner drive assembly
[6] HDD
[7] Left deck pull-out drive assembly
• Left deck pull-out clutch (CL4)
[8] Feeding fan (FM1)
[9] Left deck pickup motor (M24)
[10] Left deck pickup releasing solenoid
(SL7)
[11] Left deck lifter drive assembly
• Left deck lifter motor (M4)
• Left deck level sensor upper/lower
(PS49, PS50)
[12] Power supply transformer
[13] Cassette 3 length detection
• cassette 3 level detection (SVR2)
• cassette 3 paper width detection
(SVR4)
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 7 EXTERNALS AND CONTROLS
[14] Cassette 4 length detection
• cassette 4 level detection (SVR3)
• cassette 4 paper width detection
(SVR5)
[15] Right deck pickup releasing solenoid
(SL7)
[16] Vertical path lower motor (M27)
[17] Right deck pickup motor (M11)
[18] Right deck lifter drive assembly
• right deck lifter motor (M5)
• right deck level sensor upper/lower
(PS47, PS48)
[19] Right deck pickup motor (M11)
[20] Vertical path upper motor (M26)
[21] Vertical path duplex feeding motor
(M25)
[22] Pre-registration motor (M17)
[23] Controller cooling fan (FM4)
7-17 P
