CHAPTER 6 SELF DIAGNOSIS
E601
Main Cause The wiring is faulty (short circuit, open circuit). The hard disk drive is
faulty. The DC controller PCB is faulty. The main controller PCB is faulty.
Mode of
Detection
0000 The main controller PCB has detected an error in control data
0001 The main controller PCB has found an error in the control data in
E602
Main Cause The wiring is faulty (short circuit, open circuit). The hard disk drive is
faulty. The main controller PCB is faulty.
Mode of
Detection
0001 A mount error was detected when the hard disk was started up
0002 A data read error (from the hard disk) was detected when the hard
0003 a sector error is found on the hard disk.
0004 an error is found in the read/write address for the hard disk.
E607
Main Cause The hard disk fan (FM7) is faulty. The wiring is faulty (short circuit, open
circuit). The DC controller PCB is faulty.
Mode of
Detection
0000 While the hard disk fan (FM7) is being driven, the clock signal
E677
Main Cause The various printer board (accessories) are faulty. The main controller PCB
is faulty.
Mode of
Detection
0001 An error has occurred in the communication between the various
6-8 T
while an image was transmitted between the main controller PCB
and the hard disk drive.
transfer of images between main controller PCB and the DC con-
troller PCB.
from the boot ROM.
disk was started from the boot ROM.
(FM7CLK) does not arrive for 5 secs or more.
printer boards (accessories) and the main controller PCB.
