F. List of Special Tools
The following special tools will be needed in addition to the standard tools set:
No. Name
1 Digital
multimeter
2 Door switch
3 Mirror
positioning tool
(front, rear)
4 NA-3 Test Sheet
5 Potential sensor
electrode
COPYRIGHT © 2001 CANON INC.
Toll No.
FY9-2002
TKN-0093
FY9-3009
FY9-9196
FY9-3012
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
Shape Rank
A
A
B
A
B
APPENDIX
Remarks
Used when making
electrical checks.
Used when positioning
the No. 1/No. 2 mirror.
Used when adjusting/
checking images.
Used to make zero-level
checks on potential
sensors.
A-13
