<INPUT KEY/DISPLAY>
Key
counter check
copy
scan
0 to 9
stop
ID
additional functions USER
<PART-CHK>
Checking the operation of various loads.
CL
Use it to select the clutch to check.
Using the Mode
1) Select the mode item.
2) Using the keypad, enter the code of the clutch in question (T05-501-02).
3) Press the OK key.
CL-ON
Use it to check the operation of a clutch.
Using the Mode
1) Select the mode item, and press the OK key.
• ON → 10 secs OFF → ON → 10 secs OFF → ON → OFF
COPYRIGHT © 2001 CANON INC.
Screen display
BILL
COPY
OTHER
0 - 9
STOP
ID
T05-501-01
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
Key
start
mail box
reset
energy saver
clear
interrupt
guide
COPIER>FUNCTION
Screen display
START
PB
RESET
STAND BY
CLEAR
INTERRUPT
?
5-69 T
