Canon Image Reader-A1 iR5000i Service Manual page 788

CHAPTER 5 SERVICE MODE
<DC-CON (2/8)>
Address Bit Notation
3 PS10
4 PS12
5 PS17
6 PS18
7
8 SV1
9 SV1
10 CL2
11 PS5
12 PS9
13 PS3
14
15 SW2
IO-P04 0
1
2
3 PS15
4 PS16
5 SV2
6 SV2
7
8 TH2
9 TH1
10
11
12 RL1
13
14
15
IO-P05 0 FM1
1 FM2
2 FM6
3 FM3
4 FM7
5 FM4
6 FM8
7 FM5
8 PS47
5-22 T
left deck lifter sensor signal
left deck limit sensor signal
cassette 3 lifter sensor signal
cassette 4 lifter sensor signal
cassette 4 universal detection
cassette 4 length detection signal 0
cassette 4 length detection signal 1
registration roller clutch drive signal
right deck open/closed detection sensor signal
left deck open/closed sensor signal
right cover open/closed detection signal
not used
front cover open/closed detection signal
duplexing unit detection signal
fixing/feeding unit detection signal
hard disk unit detection signal
cassette 3 open/closed sensor signal
cassette 4 open/closed sensor signal
cassette 3 size detection signal 0
cassette 3 size detection signal 1
not used
fixing sub thermistor error detection signal 1
fixing main thermistor error detection signal
E001 error hard detection signal
fixing sub thermistor error detection signal 2
main relay OFF detection signal
main SSR error signal
sub SSR error signal
DC controller switch signal
separation feeder fan stop detection signal
primary charging cooling fan stop detection signal
DC power supply fan stop detection signal
heat discharge fan stop detection signal
hard disk fan stop detection signal
controller cooling fan stop detection signal
duplexing feed fan stop detection signal
de-curling fan stop detection signal
right deck paper level sensor (upper) signal
COPYRIGHT © 2001 CANON INC.
Description
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
COPIER>I/O
Remarks
1: paper present
1: limit
1: paper present
1: paper present
0: universal
1: ON
1: closed
1: closed
1: closed
0: closed
0: connected
0: connected
1: absent
1: closed
1: closed
1: error
1: error
1: error
1: error
1: error
1: error
1: new
1: stop
1: stop
1: stop
1: stop
1: stop
1: stop
1: stop
1: stop
1: paper present
