3.13 The back of the print is soiled

Transfer guide
1) Is the transfer guide soiled with toner?
YES:
1.
2.
3.
Drum cleaner
2) Is the paper feeding assembly soiled with toner?
YES:
1.
2.
Fixing assembly
3) Is the fixing assembly lower roller soiled?
YES:
1.
2.
3.
NO:
1.
2.
COPYRIGHT © 2001 CANON INC.
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
Clean the transfer guide.
Check the transfer guide bias.
Check the developing assembly for leakage of toner.
Clean the feeding assembly.
Check the drum cleaner assembly for leakage of waste toner.
Clean the fixing assembly lower roller.
Clean the fixing assembly inlet guide.
Check the fixing upper roller and the web for dirt.
Check the following:
Registration roller for dirt.
Delivery roller and separation claw for dirt.
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
