The following signals are used:
[1] separation charging leakage detection signal; '0' when an excessively high or low level
of current is detected.
[2] separation charging current control signal; when about 3 V or higher and lower than 11
V, the output of the separation current turns ON; when about 12 V or higher, it turns
OFF.
[3] separation charging remote signal; turns on/off the output of the separation current.
