CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS

6.5.1 Reader Unit

Symbol
Photointerrupter
SIZE
Photosensor

6.5.2 Printer Unit

Symbol
Photointerrupter
4-68 T
Name Notation
PS39
PS40
PS43
Name Notation
PS2
PS3
PS4
PS5
PS6
PS7
PS8
PS9
PS10
PS11
PS12
PS13
PS14
PS15
PS16
PS17
PS18
PS19
PS20
PS21
PS22
PS23
PS24
PS25
PS26
PS27
PS28
PS29
PS30
COPYRIGHT © 2001 CANON INC.
Function
Scanner HP sensor
Copyboard cover sensor
Original sensor
Function
Right lower cover open/closed sensor
Manual feed tray open/closed sensor
Claw jam sensor
Right deck open/closed sensor
Right deck lifter sensor
Right deck paper sensor
Right deck limit sensor
Left deck open/closed sensor
Left deck lifter sensor
Left deck paper sensor
Left deck limit sensor
Cassette 3 paper sensor
Cassette 4 paper sensor
Cassette 3 open/closed sensor
Cassette 4 open/closed sensor
Cassette 3 lifter sensor
Cassette 4 lifter sensor
Right deck re-try sensor
Left deck re-try sensor
Cassette 3 re-try sensor
Cassette 4 re-try sensor
Manual feed paper sensor
Vertical path 1 paper sensor
Vertical path 2 paper sensor
Vertical path 3 paper sensor
Vertical path 4 paper sensor
Laser write start sensor
Registration paper sensor
Duplex pre-registration sensor
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
