CHAPTER 5 SERVICE MODE
<CLEAR>
Cleaning the RAM, Jam History, and Error Code History
The data is cleared only when the main power switch has been turned off and then on; be
sure to turn it off and then on at the end.
ERR
Use it to clear error codes.
Using the Mode
1) Select the mode item, and press the OK key.
2) Turn off and then on the main power switch.
DC-CON
Use it to clear the RAM on the DC controller PCB.
Using the Mode
1) Select the mode item, and press the OK key.
2) Turn off and then on the main power switch.
R-CON
Use it to clear the RAM on the reader controller PCB.
Using the Mode
1) Select the mode item, and press the OK key.
2) Turn off and then on the main power switch.
SERVICE
Use it to clear the backup data of service mode (COPIER>OPTION).
Using the Mode
1) Select the mode item, and press the OK key.
2) Turn off and then on the main power switch.
JAM-HIST
Use it to clear the jam history.
Using the Mode
1) Select the mode item, and press the OK key.
2) Turn off and then on the main power switch.
ERR-HIST
Clearing the Error History
Using the Mode
1) Select the item, and press the OK key.
2) Turn off and then on the main power switch.
E354-CLR
---
E355-CLR
---
5-72 T
