CHAPTER 3 INSTALLATION

5. Mounting the Original Holder

Step Work Checks/remarks
1 Mount the original holder [2] to the
[2]
machine (right) using the two
[1]
stepped screws [1] that come with the
machine.
If the original holder is not needed,
fit the two rubber caps that come
with the machine instead.
If it is difficult to mount the original
holder, try loosening the two mount-
ing screws.
3-32 S
