Canon Image Reader-A1 iR5000i Service Manual page 536

CHAPTER 8 PAPER DECK
3) Remove the four screws [5], and detach
the deck [6] from the deck base [7].
4) Holding the deck [8] as shown, place it
on the stack of paper prepared in step 1.
8-26 P
COPYRIGHT © 2001 CANON INC.
(left)
[7]
F08-302-02
F08-302-03
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
[5]
[6]
(right)
[5]
[8]
