FF: Types of Jams
Code
00xx
none
01xx
delay jam
02xx
stationary jam
0Axx
stationary jam at power-on
0Bxx
front cover open jam
T05-201-01
ff: Jam Sensor
Code
xx01
registration paper sensor (PS29)
xx02
laser write start sensor (PS28)
xx03
vertical path 1 paper sensor (PS24)
xx04
vertical path 2 paper sensor (PS25)
xx05
vertical path 3 paper sensor (PS26)
vertical path 4 paper sensor (PS27)
xx06
xx07
right deck feed paper sensor (PS32)
xx08
left deck feed paper sensor (PS33)
xx0B
right deck re-try sensor (PS19)
xx0C
left deck re-try sensor (PS20)
xx0D
cassette 3 re-try sensor (PS21)
xx0E
cassette 4 re-try sensor (PS22)
xx0F
claw jam sensor (PS4)
xx10
internal delivery sensory (PS35)
xx11
external delivery sensor (PS36)
xx12
delivery assembly jam sensor (PS46)
xx13
reversal sensor 2 (PS38)
xx14
reversal sensor 1 (PS37)
xx15
duplexing paper sensor (PS34)
xx16
duplexing pre-registration sensor (PS30)
xx1E
deck pickup sensor (PS101)
xx1F
deck feed sensor (PS106)
xx32
buffer path sensor (PI14)
xx33
inlet sensor (PI1)
xx34
delivery sensor (PI3)
xx35
staple tray sensor (PI4)
xx36
vertical path paper sensor (PI17S)
xx37
delivery sensor (PI11S)
T05-201-02
COPYRIGHT © 2001 CANON INC.
Type
Sensor
2000 2000 2000 2000
G: Source of Paper
Code
1
right front deck
2
left front deck
3
cassette 3
4
cassette 4
5
not used
6
not used
7
paper deck (accessory)
8
manual feed tray
9
duplexing block
FFff: Sensors for and Types of Jams
in the Feeder
x=1: 1st original picked up.
x=0: 2nd or subsequent original picked up.
Code
00x1 Post-separation sensor
(S3) delay
00x2 Post-separation sensor
(S3) stationary
00x3 Registration senor (PI1)
delay
00x4 Registration sensor (PI1)
stationary
00x5 Read sensor (S2) delay
00x6 Read sensor (S2) stationary S2
00x7 Delivery reversal sensor
(S1) delay
00x8 Delivery reversal sensor
(S1) stationary
00x9 User ADF open
00xA ADF open
00xB User cover open
00xC Cover open
00xD Residual
00xE Pickup fault
00xF Timing error
CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 SERVICE MODE
COPIER>DISPLAY
Description
T05-201-03
Description
T05-201-04
Sensor
S3
S2, S3
S3, PI1
PI1
S2
S1, S2
S1, S2
PI2
PI2
SW2
SW2
PI1, S1,
S2, S3
PI5
S2
5-13 T
