Canon Image Reader-A1 iR5000i Service Manual page 93

Step
5 Remove the two fixing nip releasing screws[7].
6 Close the fixing/feeding assembly.
COPYRIGHT © 2001 CANON INC.
Work
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 3 INSTALLATION
Checks/remarks
[7]
[7]
3-13 S
