Motor
4) Do the reversal motor (M14), duplex feeding left motor (M29), du-
NO:
COPYRIGHT © 2001 CANON INC.
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
plex feeding right motor (M18), and vertical path duplex motor
(M25) rotate at the correct timing?
Replace the motor.
