CHAPTER 5 SERVICE MODE
<INSTALL>
Modes for Installation
TONER-S
Use it to supply toner from the hopper to the developing assembly and to
stir the toner inside the developing assembly.
Caution • Make sure that the developing assembly is properly mounted before
• Do NOT turn off the power while the machine is in operation.
Using the Mode
1) Select the mode item, and press the OK key.
2) The machine executes toner supply. (about 8 to 10 min)
• While toner is being supplied, the duration (sec) is counted down start-
3) The machine stops automatically at the end of the operation.
STRD-POS
Use it to execute auto adjustment of the position of the CCD read position
for stream reading mode.
Caution • Execute this mode at time of installing an ADF or if you have removed
Using the Mode
1) Select this item, and press the OK key.
• Auto adjustment is executed.
2) See that the adjustment ends automatically.
3) Record the updated setting indicated in service mode on the service
label: COPIER>ADJUST>ADJ-XY>STRD-POS.
CARD
Setting Up the Card Reader
Enter the number of the card to use. (detail: 1)
(from 1 to 2001; as many as 300 cards may be used starting with the card
whose number has been entered.)
Initialize the card control data.
• Initialize the card names (group ID; from registered number)
• Initialize the ID number for the card in question.
5-60 T
pressing the OK key.
ing at '600 sec'.
and then installed the existing ADF.
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
COPIER>FUNCTION
