CHAPTER 3 STANDARDS AND ADJUSTMENTS

1.3.4 Duplex Feeding Unit

1) Adjust the image margin as indicated using service mode: COPIER>ADJUST>Feed-
ADJ>ADJ-REFE.
Decreasing the ADJ-REFE setting
(A decrease by ' 10' will
ecrease the margin by 1 mm.)
1.3.5 Side Paper Deck
1) Slide out the compartment, and turn the two screws to adjust the position of the latch
plate of the deck open solenoid. (At this time, use the index on the latch plate as a
guide.)
3-4 T
F03-103-06
Latch plate
F03-103-07
COPYRIGHT © 2001 CANON INC.
Edge of paper
Increasing the ADJ-REFE setting
(An increase by ' 10' will increase
the margin by 1 mm.)
2.5±2.0mm
0 0
2 2
4 4
6 6
8 8
10 10
Index
Screws
