3.15 The print has a displaced leading edge
(appreciably large margin)

3.16 The print has a displaced leading edge (large margin)

3.17 The print has a displaced leading edge (no margin)

Placement of originals
1) Is the original placed correctly?
NO:
Pickup assembly
2) Make prints using the following source of paper. Is the displaced lead-
ing edge different?
1.
2.
3.
4.
YES: Check the source of paper in question for the following:
1.
2.
3.
Registration clutch, Registration roller
3) Make adjustments in service mode: COPIER>ADJUST>Feed-
ADJ>REGIST. Is the problem corrected?
YES: End.
NO:
1.
2.
COPYRIGHT © 2001 CANON INC.
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
Place the original correctly.
Let/right front deck
Cassettes
Side paper deck
Duplex feeding assembly (double-sided print)
Life of each roller
Paper lint on each roller
Dirt on the paper path
Check the registration roller for deformation/wear.
Check the registration roller drive system.
