• The cassette heater (H4) used for the 100V model operates as follows, assuming that the
environment switch (SW3) remains on:
Cassette heater
switch (SW4)
Cassette heater (H4)
• The cassette heater (H4) used for the 230V model operates as follows, assuming that the
environment switch (SW3) remains on:
Cassette heater
switch (SW4)
Cassette heater (H4)
COPYRIGHT © 2001 CANON INC.
Main power
switch (SW1)
ON OFF
ON OFF
T05-700-01
Main power switch
(SW1) OFF
ON OFF
ON OFF
T05-700-02
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 PICK-UP/FEEDING SYSTEM
Standby/front During printing
cover open
ON OFF ON
ON OFF OFF
Standby/front During printing
cover open
ON OFF ON
ON OFF ON
In power save
mode
OFF ON OFF
OFF ON OFF
In power save
mode
OFF ON OFF
ON ON ON
5-41 P
