Step
9 Mount the reader power cable [10] as shown.
1. If the test print image shows
Memo
distortion, correct the height of
the reader unit using the ad-
justing wrench that comes with
the machine.
2. Use the reader unit anti-con-
densation heater that comes
with the machine as
10
In case of installing the Image
Memo
Reader-A1 by attaching to the
main unit, do not throw away a
blanking plate and blanking seals
included in the package and be
sure to keep them.
COPYRIGHT © 2001 CANON INC.
Work
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 3 INSTALLATION
Checks/remarks
[10]
3-9 S
