1.3.2 Start-Up Sequence
When the main power switch is turned on, the CPU on the main controller PCB executes
the self-diagnosis program stored in the boot ROM.
The self-diagnosis program is designed to check the condition of the SDRAM and hard
disk, and indicates any error it detects on the control panel in the form of an error code.
Related Error Code
E601-0000, -0001
Error in Image Transfer Information
E602-0001, -0002
Write/Read Error
COPYRIGHT © 2001 CANON INC.
SD RAM
System Image
area data area
CPU
Self-diagnostic Boot
program program
Boot ROM
Main controller PCB
: Access to the program at execution.
F02-103-02
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 2 MAIN CONTROLLER
Hard disk drive (HDD)
